INDIA “S MOST ADVANCED SUCCESS TECHNOLOGY
TWO AC ATM /SERVER ROOM AC TIMER DIGITAL DISPLAY MODEL-ACSHR 7036
The digital AC ATM Timer is A Cyclic Timer Unit Meant for Cyclic Operation of two any type of Air Conditioner. Each AC can be kept ON from 1 hr. to 12 hrs. (Max. in this unit) AC On condition is shown by their respective Display. After the set time of the first AC is over the second AC will turn ON.
Dynamic AC ATM Timer latest Micro controller Based Technology. It’s very economic model and very compact in industry, it has facility 3 minute delay time, AC1/AC2 ON indication. It has 1 to 12 hrs programmable timers; two heavy duty sturdy relay with heavy 30 Amps connector each capable To take load up to 2 ton window or split AC with auto/ manual facility. Company provides 12 months unconditional warranty. it has LCD Fully Digital Display can see ALL Parameter like AC1 on /AC2 on ,balance time and set timer,AC1 MANUAL /AC 2 MANUAL facility also provided .
1] Latest Micro controller based technology.
2] LCD Fully Digital Display Model.
3] Supply Voltage: 230 V AC, 50 Hz ± 15%
4] Contact Rating: 30 A heavy duty relay at 230 V AC for Outputs, C/NO OUTPUT Optional .
5] Display: LCD display 2*16 character,
6] Programme: - 1 hr to 12 hrs,
7] Connector: - 30 amps heavy duty Bakelite Connector.
8] Programme switches: - 4 nos. tactile switches, set ac1Time /set ac2Time, Set ac1 manual /Set ac2 manual.
9]display continue show run ac status ,set time, run time ,ac manual or auto mode ,
10] User friendly setting.
11] Operating temperature:-0 to 100*C
13] Wall mounting ;approx-175W*120H*65H mm (with terminal).
14] Both AC Works Equal Time
15] Delay Time Facility ,Suitable for window ,splits, package or three phase AC.
16] 12 Months Warranty .
